| Power | We accept worldwide voltage customization,can design the volatge as per your request |
| Lifting height | 1500mm（standard type）We can design the lifting height according to clients requirements(Max.height 9m) |
| Platform size | 1430mm（L） x 1000mm（W） |
| speed | 40mm/s |
| Load capacity | 300kg |
| In and out direction | 90° Or 180° |
| Platform size type | Pattern non-slip metal plate |
| Net weight | >400kg |
| Motor | 1.5KW 220V/AC Or 110V/AC |
| Working environment | Indoor and outdoor |
| working temperature | -20°C — 60°C |
| Installation mode | No foundation pit installation (fixed directly to concrete ground) |
| Emergency stop button | Press the emergency button switch to control the machine to run, rise or fall |
| Aluminum alloy bar | When the platform is lowered will stop running immediately when it encounters an obstacle. |
The correct selection of various safety configurations of the wheelchair lift for the disabled can maximize the function of the wheelchair lift and achieve the best use effect.
Safety measures for wheelchair lifts:
1. Safety interlock: the lifting platform cannot operate during any abnormal operation.
2. Safety touch panel: When the safety touch panel encounters an obstacle during operation, the operation of the wheelchair lift will stop immediately.
3. Emergency descent: When there is no power or failure, pull the manual valve to manually descend the home elevator.
4. Safety handrail: protect the user's safety when going up and down.
5. Safety organ-type dust cover: prevent foreign matter from entering the body.
Instructions for the use of home elevator wheelchair lifts:
1. Before use, it must be lifted and lowered without load to check whether the hydraulic system of the wheelchair lifting platform is normal.
2. In order to ensure the safety of the user, when using the wheelchair lift, someone must accompany it.
3. The hydraulic oil in the oil tank should be replaced every 500 hours of operation.
4. Household elevators are not allowed to load and lift goods.
5. Do not overload and do not shake violently during use.
6. It is strictly forbidden to carry out any live work in the elevator.
7. When the working pressure of the machine is found to be too high or the sound is abnormal, stop the machine immediately for inspection to avoid serious damage to the home elevator.
