1. What is the biggest difference between this wheelchair lift and ordinary elevator?
The biggest feature of the disabled lift is that it does not require a pit, and is directly installed on the ground. It is generally used for on-site barrier-free renovation.
2. What kind of control method is used for the elevator for the disabled?
The control method of wheelchair elevator generally adopts electric control, that is, press the button and the elevator runs, and release the button to stop the movement.
We can design the wheelchair lift according to customer's requested platform size,lifting height and the load capacity.Its better to send us your site picture,so we can design for you accordingly.
As for material ,we maintly have two types,one is welding iron material,another is high-end aluminum material,you can choose according to your requirements.
Power | We accept worldwide voltage customization,can design the volatge as per your request |
Lifting height | 1500mm（standard type）We can design the lifting height according to clients requirements(Max.height 9m) |
Platform size | 1430mm（L） x 1000mm（W） |
Speed | 40mm/s |
Load capacity | 300kg |
In and out direction | 90° Or 180° |
Platform size type | Pattern non-slip metal plate |
Net weight | >400kg |
Motor | 1.5KW 220V/AC Or 110V/AC |
Working environment | Indoor and outdoor |
working temperature | -20°C — 60°C |
Installation mode | No foundation pit installation (fixed directly to concrete ground) |
Emergency stop button | Press the emergency button switch to control the machine to run, rise or fall |
Aluminum alloy bar | When the platform is lowered will stop running immediately when it encounters an obstacle. |
