The wheelchair lift is a new generation of lifting equipment that is more economical and more efficient than the inclined wheelchair lifting platform and ordinary elevators. It does not need to modify the structure of the existing building, nor does it need to carry out additional construction. It uses the smallest installation space and can help the elderly and the disabled to come and go freely.
The wheelchair lift consists of four parts: main frame, lift, platform, and outer wall.
The main frame supports the elevator and the rail, the lifting fence, which contains the oil pressure source and the controller.
It can be used indoors and outdoors, with its own frame, no hoistway, simple operation, and customized colors.
Power | We accept worldwide voltage customization,can design the volatge as per your request |
Lifting height | 1500mm（standard type）We can design the lifting height according to clients requirements(Max.height 9m) |
Platform size | 1430mm（L） x 1000mm（W） |
Speed | 40mm/s |
Load capacity | 300kg |
In and out direction | 90° Or 180° |
Platform size type | Pattern non-slip metal plate |
Net weight | >400kg |
Motor | 1.5KW 220V/AC Or 110V/AC |
Working environment | Indoor and outdoor |
working temperature | -20°C — 60°C |
Installation mode | No foundation pit installation (fixed directly to concrete ground) |
Emergency stop button | Press the emergency button switch to control the machine to run, rise or fall |
Aluminum alloy bar | When the platform is lowered will stop running immediately when it encounters an obstacle. |
