Hydraulic Wheelchair Lift With Ramp

Hydraulic Wheelchair Lift With Ramp

The barrier-free lift is a lift specially designed and manufactured for the disabled. In order to facilitate the travel and sightseeing of the disabled, in communities, hospitals, schools, hotels, hotels, public places and other places. Barrier-free elevators are installed next to the escalator in the tourist elevator passage. The barrier-free lift can accommodate wheelchairs and vehicles. The disabled or people with limited mobility only need to press the help buttons at both ends, and the staff on duty will immediately turn on the automatic lift. As the price of barrier-free wheelchair lifts has been declining in recent years, many private residences are equipped with wheelchair lifts in order to facilitate access for the elderly.
Send Inquiry
Description

electric wheel chair lifts

The barrier-free lift is a lift specially designed and manufactured for the disabled. In order to facilitate the travel and sightseeing of the disabled, in communities, hospitals, schools, hotels, hotels, public places and other places. Barrier-free elevators are installed next to the escalator in the tourist elevator passage. The barrier-free lift can accommodate wheelchairs and vehicles. The disabled or people with limited mobility only need to press the help buttons at both ends, and the staff on duty will immediately turn on the automatic lift. As the price of barrier-free wheelchair lifts has been declining in recent years, many private residences are equipped with wheelchair lifts in order to facilitate access for the elderly.

Product details:

wheelchair lift handicap
wheelchair lift disabled people
2

wheelchair lift for van

Power
We accept worldwide voltage customization,can design the volatge as per your request
Lifting height
1500mm(standard type)We can design the lifting height according to clients requirements(Max.height 9m)
Platform size
1430mm(L) x 1000mm(W)
speed
40mm/s
Load capacity
300kg
In and out direction
90° Or 180°
Platform size type
Pattern non-slip metal plate
Net weight
>400kg
Motor
1.5KW 220V/AC Or 110V/AC
Working environment
Indoor and outdoor
working temperature
-20°C — 60°C
Installation mode
No foundation pit installation (fixed directly to concrete ground)
Emergency stop button
Press the emergency button switch to control the machine to run, rise or fall
Aluminum alloy bar
When the platform is lowered will stop running immediately when it encounters an obstacle.

electric lifts for wheelchair disabled


8
1
12





wheelchair lifts

wheelchair stair lift

wheelchair lift stair

lift wheelchair

wheelchair platform lift

stair lift for wheelchairs

Hot Tags: hydraulic wheelchair lift with ramp, China, manufacturers, suppliers, factory, customized, buy, cheap, for sale, made in China
